Category Name
Lawn / Garden
Weight
1,985 lbs. (900.38 kg) with (5) 18" 8-blade cutting units.
Controls
Foot operated controls: Forward and reverse traction pedal, mow/transport speed limiter. Hand operated on control panel: Parking brake lever, ignition switch, engine throttle lever, LED work light switch, on/off switch for cutting units, joystick for cutting unit lift and lower. Other controls: Steering wheel tilt control, reel speed control, backlap engagement lever.
Mowing Speed
0 - 7 mph (0 - 11.3 km/h)
Oil Capacity
3.5 U.S. qt. (3.3 L)
Width Of Cut
82" (208 cm)
Fuel Capacity
7.5 U.S. gal. (28.4 L)
Overall Width
94" (238.8 cm)
Reel Diameter
5 in. (12.7cm)
Transport Width
91" (231 cm)
Electrical System
Heavy-duty 12-volt battery, 570 CCA; 40 amp alternator/regulator. Electronic control unit is microprocessor based, solid state control unit with diagnostic capabilities.
Bedknife Adjustment
Precision machined cutting units maintain levelness and hold adjustments. Dual Precision Adjustment (DPA) allows quick bedknife to reel adjustment.
Height Of Cut Range
8-Blade: 0.5" - 1.5" (13 mm - 38 mm) 11-Blade: 0.25" - 0.75” (6 mm -19 mm)
Ground Speed - Forward
0 - 10 mph (0 - 16.1 km/h)
Ground Speed - Reverse
0 - 3.5 mph (0 - 5.6 km/h)
Hydraulic Fluid Capacity
6 U.S. gal. (22.7 L)
Clip Frequency/Backlapping
5" reel 2,350 (+/- 150) rpm max reel speed, at highest setting. 200 rpm max at low idle and lowest setting for backlapping.
Cooling System Description
Aluminum side-by-side oil cooler/radiator. 8.5 fins per inch, wavy fin, non-louvered. 5.25 quart (4.9 liter) capacity.
Cutting Unit Type/Configuration
Five hydraulically driven, balanced, DPA cutting Units. Frame precision manufactured, die-cast aluminum for increased strength, simple click adjustment maintenance.
